目镜 Eyepiece |
大视野 WF10X视场数中22mm)Wide feld WF10X(feld number:$22mm) |
||
|
无限远平场消色差物镜 Infinity planachromatic objective |
DZ-8(配明场物镜) Equipped with bright feld objectives |
PLL10X0.25 工作距离:5 mm PLL10X0.25(Work distance):5 mm |
|
|
PLL20X0.40 工作距离:8.80 mm PLL20X0.40(Work distance):8.80 mm |
|||
|
PLL50X0.70 工作距离:3.68 mm PLL50X0.70(Work distance):3.68 mm |
|||
|
PLL100X0.85(干式)工作距离:0.40mm PLL100X0.85(Dry)(Work distance):0.40 mm |
|||
|
DZ-8MA(配明/暗场物镜) Equipped with bright & dark fieldobjectives |
PL L5X0.12 BD 工作距离:8.05 mm PLL5X0.12 BD(Work distance):8.05mm |
||
|
PLL10X0.25 BD工作距离:7.86mm PLL10X0.25 BD(Work distance):7.86 mm |
|||
|
PLL20X0.40 BD工作距离:7.23mm PLL20X0.40 BD(Work distance):7.23mm |
|||
|
PLL50X0.70 BD工作距离:2.50mm PLL50X0.70BD (Work distance):2.50mm |
|||
|
目镜筒 Eyepiece tube |
45°倾斜,瞳距调节范围53~75mm. Inclination angle is 45"and interpupillary distance is 53~75mm. |
||
|
调焦机构 Focus system |
粗微动同轴调焦,带锁紧装置,微动格值:2um. Coaxial coarse/fne focus, with tension adjustable, minimum divsion of fine focusing is 2ym. |
||
|
转换器 Nosepiece |
五孔(内向式滚珠内定位)Quintuple(Backward ball bearing inner locating) |
||
|
载物台 Stage |
机械移动载物台，外形尺寸:242mmX200mm，移动范围30mmX30mm. Mechanical stage overall size: 242mmX200mm and movng range : 30mmX30mm. |
||
|
圆形可旋转载物台板尺寸:最大外径Ф130mm，最小通光口径小于中20mm. Rotundity and rotatable stage size: maximal measurement is $130mm and minimal clear aperture is less then 中20mm |
|||
|
照明系统 lllumination system |
DZ-8 |
6V30W卤素灯，亮度可调6V30W 6V30W halogen and brightness enable control |
|
|
DZ-8MA |
12V50W卤素灯，亮度可调12V50W 12V50W halogen and brightness enable control |
||
|
内置视场光阑、孔径光阑与拉板式起偏器 Integrated feld diaphragm , aperture diaphragm and puller type polarizer. |
|||
|
配磨砂玻璃，黄、绿、蓝滤色片 Equipped with frosted glass and yellow ,green and blue filters |
|||
|
选配件 Optional accessories |
目镜 Eyepiece |
分划目镜10X(Ф22mm) |
|
|
物镜:Objective |
DZ-8 |
5X、40X、60X、80X、100X(油Oil)明场物镜 Equipped with bright feld objectives |
|
|
DZ-8MA |
40X60X80X、100X明月/暗场物镜 Equipped with bright & dark field objectives |
||
|
CCD接头 CCD Adapter |
0.5X、1X |
||
|
摄像仪 Camera |
USB输出:130/300/500/1000万像素
USB output 1.3M,3.0M,5.0M,10M pixel |
||
|
VIDEO输出:380/520电视线
video output 380/520 TV line |
|||
|
数码相机接头 Digital camera adapter |
CANON(EF) NIKON( F) |
||
